Bandit 3090 tree chipper | powerful and versatile chipper for large-scale wood processing.
Whole tree wood chipper
3090 02 1 scaled
3090 03 1 scaled
Click to enlarge
BANDIT 3090 Tree Chipper | Powerful and versatile chipper for large-scale wood processing.
whole tree wood chipper

BANDIT 3090

The Bandit 3090 Whole Tree Chipper model, with a 635 mm capacity, excels in processing whole trees and large branches for efficient biomass production and land clearing. It incorporates Bandit’s distinctive Slide Box Feed System and is equipped with a 563 – 597 kW engine, making it ideal for handling substantial right-of-way jobs effortlessly.

TOWABLE or TRACK

Capacity: 635 mm
Style: Drum

ENQUIRE OR REQUEST A QUOTE
Categories: ,

The Bandit 3090 Whole Tree Chipper model is designed for high-efficiency wood processing with a 635 mm capacity. Its powerful feed system and large drum ensure consistent and efficient chipping of whole trees and large branches. This model is ideal for biomass production, forestry, and land-clearing operations.

Key features include:

  • 24-inch capacity for heavy-duty chipping
  • Powerful five-wheel feed system enables high-volume processing
  • 610mm capacity with a 914 x 660 mm throat opening, effortlessly handling whole trees and forked branches
  • Available in towable and track configurations for flexibility in various terrains
  • Can fully load wood chip trailers in under 20 minutes, depending on engine options

In conclusion, the Bandit Model 3090 Whole Tree Chipper stands as the ultimate solution for high-efficiency wood processing, boasting a robust 635 mm capacity and equipped with Bandit’s powerful Slide Box Feed System. Whether in towable or track configurations, it excels in handling substantial biomass and land-clearing tasks with ease and reliability.

MEASUREMENTS

Towable Track
Length 11 890 mm 11 400 mm
Width 3 048 mm 2 591 mm
Height 3 810 mm 3 810 mm
Weight  24 494 kg 28 123 kg

SPECIFICATIONS

Towable Track
Capacity 635 mm  635 mm
Opening 660 mm x 914 mm wide 660 mm x 914 mm wide
Drum 940 mm dia x 914 mm wide 940 mm dia x 914 mm wide
Knives .625″ thick x 6″ wide x 12.125″ long in (6) pockets .625″ thick x 6″ wide x 12.125″ long in (6) pockets

ENGINE

Towable Track
Engine 755 – 800 HP  755 – 800 HP
Kilowatt 563 – 597 kW 563 – 597 kW
Fuel Tank 757.1 L 1 135.6 L
Hydraulic Tank 757.1 L 707.9 L
