The Badger 6 XL is a compact yet powerful towable drum-style wood chipper, crafted for professionals who require high performance and durability. Designed for tree care experts, municipalities, farmers, and rental businesses, it handles logs up to 175mm in diameter with remarkable efficiency.
Engineered for ease of use and reliability, the Badger 6 XL ensures superior chip quality, reduced maintenance, and extended blade life, making it the ideal assistant for demanding chipping tasks.
|
Feature |
Details |
|---|---|
|
Model |
Badger 6 XL |
|
Type |
Towable, Hand-fed, Drum-style Wood Chipper |
|
Capacity |
Up to 175mm diameter logs |
|
Drum Size |
390mm diameter × 306mm wide |
|
Feed Wheels |
2 × 165mm diameter × 267mm wide with bottom cleanout door & adjustable downward pressure springs |
|
Engine Options |
30–65 HP (23–49 kW) Petrol, PTO, Diesel |
|
Blade Configuration |
– 2 Staggered Blades (Coarse Chips) – 4 Staggered Blades (Finer Chips) |
|
Hopper Opening |
616mm (H) × 1070mm (W) |
|
Folding Tray |
730mm (H) × 1200mm (W) |
|
Feed Opening |
277mm × 258mm |
|
Discharge Chute |
360° Manual Rotation with Adjustable Chip Deflector |
|
Feed System |
Slide box in-feed with replaceable slides and high-torque, parallel hydraulic feed rollers |
|
Hydraulic Assist |
Enhanced down pressure for easier feeding, reduces chainsaw work |
|
Chip Quality |
Superior chip quality, extended blade life, fewer trips to the dump |
|
Automatic Reversing Auto-Feed |
Standard |
|
Warranty |
– 1 Year / 2,000 Hours Standard – 3 Years / 3,000 Hours “GUTS” Extended Warranty |
|
Ideal For |
Tree Care Professionals, Municipalities, Farmers, Rental Companies |
| Model |
Diesel ,Petrol ,PTO |
|---|
SPECIFICATIONS
|
Specification |
6PTOXL |
6PXL |
6DXL |
|---|---|---|---|
|
Production |
40–85 m³ / day |
50 m³ / day |
70 m³ / day |
|
Power / Engine |
PTO power required: 23–49 kW (30–65 hp) |
31–37 HP (23–28 kW) Briggs & Stratton Vanguard Petrol Engine |
49 HP (37 kW) Perkins 404d-22 Diesel Engine |
|
Trailer Lights |
Standard |
— |
— |
|
SABS Roadworthy Trailer |
Optional (braked coupler and axle) |
Standard |
Standard |
|
Automatic Auto-Reversing Feeding System |
Standard |
Standard |
Standard |
|
Onboard Self-contained Electrical Power |
Standard (no electrical connection required) |
— |
— |
|
Hydraulic Lift Cylinder |
Standard |
Standard |
Standard |
|
Direct Drive |
— |
Standard |
Standard |
|
Length |
3650mm (Closed Hopper) |
3550mm (Closed Hopper) |
3680mm (Closed Hopper) |
|
Width |
1640mm |
1640mm |
1630mm |
|
Height |
2150mm |
2150mm |
2150mm |
|
Weight |
1150kg |
1200kg |
1410kg |
